This medium-power density infrared radiant unit is highly energy efficient. It is specially suited to drying aluminium and metal parts. As well as conserving energy, it allows for more compact installation of industrial ovens. It average curing temperature is between 140°F and 480°F. It combines all the benefits of the Sunkiss USA Thermoreactor®: safety, time-saving, air recycling and cleanliness.
Power: 37500 BTU
Weight: 81.54 lb
Dimensions: 590 x 750 x 425 mm
Power supply: Naturat Gas
Gas pulse settings: 20″wc to 60″wc
Electrical preheating : 10 min
Wall fixing : 556 x 706 x 100 mm
Thermoswitch security
Radiant surface : 470 x 470 mm
Master unit for max. 3 auxiliary unit:
– Oxygenation fan
– Starter and main gas solenoid valves
– Electrical strip connection
Power: 13500 BTU
Weight: 70.5 lb
Dimensions: 590 x 750 x 425 mm
Power supply: Natural Gas
Gas pulse settings : 20″ to 60″ wc
Electrical preheating : 10 min
Wall fixing : 556 x 706 x 100 mm
Thermoswitch security
Radiant surface : Ø 310 mm
Master unit for max. 3 auxiliary units:
– Oxygenation fan
– Starter and main gas solenoid valves
– Electrical strip connection.
Power: 112600 BTU
Weight: 154 lb
Dimensions: 2000 x 800 x 550 mm
Power supply: Natural Gas
Gas pulse settings: 20″ to 60″wc
Electrical preheating : 10 min
Wall fixing : 1782 x 706 x 100 mm
Thermoswitch security
Radiant surface : 1570 x 470 mm
Applications for industrial drying ovens of the Air Boost range.
| Applications for industrial heating ovens |
|---|
| Any aluminium and metal parts |
ALL THE BENEFITS
